Description
The globally certified BLD-100-V -LCS000 Series is a dual-stage high-efficiency smart LED driver. Its 2% minimum level and high-frequency PWM output provide a strobe flicker-free user experience.
With a 100k-hour long life and a 7-year warranty, it offers high confidence for luminaire users. It supports not only traditional dimming control but also DALI 2.0 and other protocols.
Comprehensive protections include digital OTP (Over Temperature Protection), SCP (Short Circuit Protection), and OCP (Over Current Protection) with auto-recovery, ensuring secure 24-hour non-stop operation for luminaires.
| Input Voltage | 108~305Vac or 127V-420Vdc |
| Input Frequency | 47~63Hz |
| Power Factor | >0.9@60-100%load, refer to PF vs. Load curve |
| THD | <15%@60-100%load, refer to THD vs. Loadcurve |
| Input Current | 2.2Amax@120Vac & Full-Load, 1.1Amax@220Vac & Full-Load |
| Surge Protection | Line to line 6kV, line toground 10kV, IEC 61000-4-5 |
| Output Over Current | 120% lo, typ. |
| Short Circuit | Auto recovery. The output recovers when short is removed. |
| Over Temperature | Turn off the output when Tc≥105±10°C; Auto Recovery When Tc≤70±10°C |
| Operating Temperature | Case Temperature Tc =-40°C~+90°C; 10%RH~100%RH |
| Storage Temperature | -40°C~+85°C; 5%RH~100%RH |
| MTBF | ≥280,000 hours, 75°C case temperature (MIL-HDBK-217F) |
| Lifetime | ≥100,000 hours, 75°C case temperature, refer to life vs. Tc curve |
| Case Temperature | 90°C max, marked in the Tc point of label |
